Stainless Steel 304 Seamless Pipe Manufacturer | ASTM A312
What is Stainless Steel 304 Seamless Pipe?
Stainless steel 304 seamless pipe is produced from a solid TP304 billet that is heated, pierced into a hollow raw pipe, then cold drawn or cold rolled to achieve the required outside diameter and wall thickness. The pipe is subsequently solution annealed, pickled, straightened, inspected, and cut to length. Grade 304 is an austenitic chromium-nickel stainless steel, typically containing 18–20% chromium and 8–11% nickel, which provides a useful combination of general corrosion resistance, strength, toughness, formability, and weldability. Manufactured to ASTM A312, ss 304 seamless pipe is commonly used for normally industrial applications, Its seamless structure contains no longitudinal weld seam and provides a continuous pipe wall against welded pipe, Its chemical composition and seamless construction give 304 stainless steel seamless pipe broad application possibilities, strength, and durability. As a manufacturer, we ensure not only that its chemical composition complies with international standards, but also that its mechanical strength and performance meet the applicable requirements. Need a quotation? Contact us today.
How is 304 Stainless Steel Seamless Pipe Manufactured?
304 stainless steel seamless pipe is produced by heating and piercing a solid billet to form a hollow shell, followed by cold drawing, or cold rolling to achieve the required dimensions. The pipe is then solution annealed, straightened, cut, pickled.
Learn more in our stainless steel seamless pipe manufacturing process guide.
ASTM A312 TP304 Seamless Pipe Specifications
| Specification | Available Range |
|---|---|
| Product | Stainless Steel 304 Seamless Pipe |
| Standard | ASTM A312 / ASME SA312 |
| Material Grade | TP304 |
| UNS Designation | S30400 |
| Manufacturing Process | Seamless, Cold drawn or Cold rolled |
| Outside Diameter | 10.3 – 762 mm |
| Nominal Pipe Size | NPS 1/8″ – 30″ |
| Wall Thickness | According to applicable pipe schedule |
| Pipe Schedules | SCH 5S, 10S, 40S, 80S; SCH 10 – 160; STD, XS and XXS, subject to NPS |
| Length | Random length, fixed 6 m, or custom fixed length |
| Pipe Ends | Plain end or bevelled end |
| Delivery Condition | Solution annealed and pickled |
| Dimensional Standard | ASME B36.19M or ASME B36.10M, as specified |
| Custom Services | Cutting, bevelling, marking and special packaging |
ASTM A312 TP304 Chemical Composition
| Grade | C | Mn | P | S | Si | Cr | Ni |
|---|---|---|---|---|---|---|---|
| TP304 | ≤0.08% | ≤2.00% | ≤0.045% | ≤0.030% | ≤1.00% | 18.0–20.0% | 8.0–11.0% |
Mechanical Properties of ASTM A312 TP304
| Grade | Tensile Strength, min. | Yield Strength, min. | Elongation, min. |
|---|---|---|---|
| TP304 / S30400 | 515 MPa | 205 MPa | 35% |
Outside Diameter Tolerances
| Specified Outside Diameter, D | Permitted Variation |
|---|---|
| 10.3 ≤ D ≤ 48.3 mm | +0.4 / −0.8 mm |
| 48.3 < D ≤ 114.3 mm | +0.8 / −0.8 mm |
| 114.3 < D ≤ 219.1 mm | +1.6 / −0.8 mm |
| 219.1 < D ≤ 457.2 mm | +2.4 / −0.8 mm |
| 457.2 < D ≤ 660.4 mm | +3.2 / −0.8 mm |
| 660.4 < D ≤ 864.0 mm | +4.0 / −0.8 mm |
Wall Thickness Tolerances
| Nominal Pipe Size | t/D Ratio | Permitted Variation from Nominal Wall |
|---|---|---|
| NPS 1/8″ - 2 1/2″ | All ratios | +20.0% / −12.5% |
| NPS 3″ - 18″ | t/D ≤ 5% | +22.5% / −12.5% |
| NPS 3″ - 18″ | t/D > 5% | +15.0% / −12.5% |
| NPS 20″ and above, seamless | t/D ≤ 5% | +22.5% / −12.5% |
| NPS 20″ and above, seamless | t/D > 5% | +15.0% / −12.5% |
TP304 Equivalent Material Designations
| ASTM / ASME | UNS | EN | JIS | GB/T | GOST |
|---|---|---|---|---|---|
| TP304 | S30400 | 1.4301 / X5CrNi18-10 | SUS304 | 06Cr19Ni10 | 08Х18Н10 |
How is the ss 304 seamless pipe inspected and tested, packed?
Why Choose us as Your 304 Stainless Steel Seamless Pipe Manufacturer & Supplier?
1. Extensive Inventory
We maintain approximately 2,000 tons of stainless steel products in commonly requested grades, sizes, and wall thicknesses. This inventory allows us to respond efficiently to urgent orders and different purchasing quantities.
2. In-House Manufacturing
With established production equipment, experienced workers, and controlled manufacturing processes, we produce 304 stainless steel seamless pipes according to applicable standards and customer specifications.
3. Reliable Lead Times
In-house production, available inventory, and coordinated production scheduling give us better control over order progress. Lead times are confirmed according to the required size, quantity, testing, and finishing requirements.
4. Quality Assurance and Documentation
Our quality team conducts material verification, dimensional inspection, and applicable mechanical and nondestructive testing. EN 10204 3.1 inspection certificates and heat-number traceability can be provided with each order.
